Equipment Category

Dimming and Multiplex - Strand

> View in Date Order (dated items only)

1210 (2011)
Twelve 10A dimmer or relay switched channels in a 4U high 19 inch rack module.

24 channel demultiplexer (1990 - ?)
Control of 24 analogue dimmers.

3 Pack (2006)
3 way dimmer pack

6 Pack (2006)
4U high, 19 inch digital dimmer pack.

A21
120V Dimmer Cabinet range

Act 2 (1983 - ?)
2 channel lighting control / dimmer

Act 3 (1987 - 1994)
3 channel dimmer rack (3 x 20A dimmer)

Act 3+ (1994 - ?)

Act 6 (1984 - 1994)
6 channel dimmer rack (6 x 10A dimmer)

Act 6+ (1994 - ?)
6 channel dimmer rack (6 x 10A dimmer)

Action Demultiplexer

Andi (1990s)
German Modular Dimmer System

Arc Resistances (1936)
Radial Switch type, standard type or parallel type

Automatic Dimmers (1945-1969)
Type PTU or CYU

C21
Modular dimmer system

CD80 1.2kW Pack (1989?)
24 channel compact dimmer

CD80 Advanced Electronics

CD80 Digital Pack (1992)

CD80 Dimmer Banks and Modules (1980)

CD80 Rolling Rack
The reliability of CD80 in a touring rack

CD80 Single Dimmer
Stackable single dimmer at 2.4kW, 12kW, 24kW

CD80 Supervisor
Modular Dimmer Rack System

CD90 Dimmer Rack

CRD Dimmer Rack (1963)

D54 Multiplex Protocol

DC90 Dimmer Racks and Modules (1987)

Dig 6 (1998?)
6 channel digital dimmer

DMUX
De-multiplexer

Early Metallic Dimmers (1925?)
Type A or Type B

Early Resistance Dimmers (1925?)
Wall-type or portable

EC21 (2005)
Installation dimmer rack

EC90 (1990 - ?)
Modular digital dimmer with reporter

F&D Multiplex Interface
24 channel fader & dimmer interface

JTM (1965 - 1975)
Inexpensive variable-load dimmers housed in compact 20-channel or 10-channel racks.

LD24 Dimmer Rack

LD90 (1993 - ?)
Digital Dimming

Liquid Dimmers (1915 - 1945)
Glazed earthenware jars, complete with fixed & moving lead cones.

MCM (Modular Crate Mounted) (1978)
30 x 20A or 60 x 10A Thyristor Dimmers

Mini 2 Dimmer Rack (1971)

Mini T Dimmer Rack (1970)
6 way dimmer pack. 50 - 1000W per channel.

Minipak (1978)
12 channel dimmer

Multimux 48
Interface between analogue dimmers and DMX512 or D54

Multiplex F + D Interface
Converts D54 and analogue control input to analogue control output on either 8 pin bleecon or D connector.

Perma 12 (1977)
Wall-mounting 12 thyristor dimmer rack.

Permus (1982 - ?)
Developed from Tempus dimmers

Permus Demultiplex Unit
24 channel chassis-mounted interface unit for installation using multiplexed controls and Permus dimmers.

PIP (1986)
Plug-In Professional Dimmer Modules

Plate Resistance Dimmers (1945)
Flickerless

Portable High Power Dimmer Pack (1977)
Portable pack with 3 or 10 x 5kW maximum capacity Thyristor dimmers.

Portable Touring Equipment (1968?)

ProPack (2008)
High density high power dimming in a 2U rack mount package

PTM (1968?)
Plug-in dimmer modules and associated racks

RelayRack (2014)
12 channel 10 Amp Relay Panel

Resistance Dimmers - Electro-Magnetic Mechanical Type

S21 IGBT Dimmer Box (2008)

S72 Demultiplexer (2002)
DMX to Analogue Demultiplexer for up to 72 channels

SD/WH (1959 April)
The first 220/240V SCR dimmer

SD6 Digital Dimmer

Slate Type Slider Resistance Dimmers (1930s)

SLD Dimmers (2000)
Dimmer rack for 24 or 48 dual dimmer modules.

SMX (1989)
Strand Multiplex

STM (1975)
Successor to the JTM

Sunset Resistance Dimmers (1945)
Type A, Type A1, Type B, Type D, Wall Mounting Type

System 6 (1994)
Compact wall-mounted dimmer cabinet: 6 x 15A or 6 x 20A dimmers

Tempus (1980)
Portable dimmer packs

Thyratron (1952 - 1966)

Valve Dimming

TM (1965?)

Transformer Dimmers (1945? - ?)

TU Thyristor Unit Dimmer
5kW maximum. Basic unit dimmer for single circuit.

Tubular Resistance Dimmers (1936)
Type T1, T2, T4
