Equipment Category

Lanterns (Patt. Numbered) - Strand

> View in Date Order (dated items only)

Pattern 52A (1930s)
Focus Flood 2000W

Pattern 52B (1930s)
2000W Spotlight

Pattern 74 (1930s)
Baby MIrror Spot 250W

Patt.12 (1961 - 1966)
ADB Picture Spot with shutters and fixing plate

Patt.20 (1915 - 1925)

Patt.21 Focus Stage Arc (1925 approx)

Patt.22 Front of House Spotting Arc (1916 - 1936)
Heavy-type, 30-50 Amps.

Patt.23 (1953 - 1983)
500W profile

Patt.23/23A Stage Arc Spot (1919 - 1945)
15/20A carbon arc stage spot, slide focus

Patt.24 Half Watt Stage Flooding Lantern (1925 approx)
500/1000 Watts

Patt.25 Baby Spot Half Watt Lantern (1925 approx)

Patt.26 Baby Spot With Focussing Tray (1925 approx)

Patt.27 Float Spot (1925 - 1960)
Miniature PC spot, designed for use in float position downstage

Patt.28 Cylindrical Type (1925 approx)

Patt.30 (1920 - 1968)
Medium-Angle Batten Flood 500 Watt

Patt.32 (1922 - 1948)
100 - 150W Baby Sunray Flod

Patt.33 (1925 - 1945)
Optical Effect Lantern

Patt.34 (1924 - 1945)
1000W Panorama Flood

Patt.35 (1928 - 1963)
Arena Flood 1000 Watt

Patt.36 (1928 - 1935)
1000W Acting Area Flood

Patt.37 (1920 )
Flood

Patt.38 (1928 - 1940)
500 Watt General Outdoor Flood

Patt.41 (1952 - 1954)
100W Miniature Display Spotlight

Patt.42 (1925 - 1957)
Combined Spotting and Optical Effects Lantern

Patt.43 / Patt.43A / Patt.43B / Patt.43C (1925 approx - 1960)
1000W Focus Spot

Patt.44 (1928 approx - 1952)
500W Baby Spot

Patt.45 (1928 approx - 1978)
250W Miniature Spot (later 500W)

Patt.46 / Patt.46A / Patt.46B (1928 approx - ?)
Flood

Patt.47 (1945)
500-1000W Square Outdoor Flood

Patt.48 (1930 - 1940)
Outdoor Square Flood, 1000W

Patt.50 / 50A / 50B (1935 - 1953)

Patt.51 (1930-1960)
1000W Optical Effects Projector

Patt.52
1000 Watt Optical Effects and Slide Projector

Patt.53 (1953 - )
Prefocus Mirror Spotlight, 1000 Watt

Patt.56 (1936 - mid 1950s)

Patt.58 (1953 - )

Patt.59
Vertical Flood 1000W

Patt.60 (1945 - 1981)
500W Flood
An evolved version of the Patt.30.

Patt.63 Stelmar Spotlight (1928)
1000W Projector Lamp model, first patented by Strand in 1928

Patt.S63 / S64 / S Batten

Patt.70 Magazine Spotting Arc

Patt.73 (1936 - 1953)

Patt.75 Front of House Spotting Arc

Patt.76
Known as acting area floods (or A.A.s)

Patt.80 (1930s)
Baby Pageant 12V 100W

Patt.81
Low Voltage Spot

Patt.83 (1948 - 1951)
1000W F.O.H. Mirror Spot (skeleton type)

Patt.87 Low Voltage Lens Spot (1945)

Patt.93 (1954)
Long Range 1000W Spotlight

Patt.100 (? - 1945)

Patt.100 (later) (1967 - )

Patt.102 (1945 - )
Soft Edge Spot (1 or 2kW)

Patt.102 Mini Profile

Patt.123 (1957 - 1978)
500W Fresnel

Patt.137 (1946 - 1983)

Patt.143
500 / 1000 / 1500W Fresnel

Patt.149
Scoop 750/1000W

Patt.152 (1959 - 1972)
High intensity scene projector.

Patt.223 (1963)
1000W Fresnel

Patt.230
UV Flood

Patt.237 (1945 - 1957)
Medium or wide angle flood - 60, 100 or 150 Watt

Patt.243 (1960-1978)
2000W Fresnel

Patt.249
1250/2000 Watt Softlight

Patt.252
2kW Effects Projector

Patt.253 (1963)
1500/2000 Watt Profile

Patt.263 (1963 - 1976)
1kW Spotlight

Patt.264 (1963-1976)
Bifocal brother of Patt.263

Patt.293
Followspot

Patt.294
Followspot - Bi-Focal

Patt.501
Sunspot Mirror Arc

Patt.502
Outdoor Medium Beam Flood (1000 / 1500W)

Patt.511
Xenon Arc Followspot

Patt.537
Outdoor Baby Flood (60,100,150 Watts)

Patt.558
Narrow Angle Spotlight, 1000 Watt

Patt.560
300/500W Outdoor Wide or Medium Beam Flood

Patt.743
1000W Fresnel

Patt.750 (1970)
1kW Beamlight

Patt.793 (1973-1978)
2000W Profile Spot

Patt.803 (1978 - 1981)
650W Fresnel Spot

Patt.808 (1978)

Patt.813 (1978)

Patt.814 (1980)

Patt.823 (1978)

Patt.828 (1978 - )

Patt.833 (1978 - 1981)
Fresnel spot (replacement for Patt.45)

Patt.F1 Junior Flood
